Oil-based drilling fluid system-Temperatures stable to 200℃,density 2.1g/cm3

Customer Case Specification Oil-based drilling fluid system-Temperatures stable to 200℃,density 2.1g/cm3 Oil-based drilling fluid refers to the drilling fluid with oil as the continuous image. Water-in-oil emulsion drilling fluid is a...

  • Brand: CAMP-SHINNING
  • Availability: In Stock
  • SKU: 9999

Tags:

Customer Case Specification

Oil-based drilling fluid system-Temperatures stable to 200℃,density 2.1g/cm3

Oil-based drilling fluid refers to the drilling fluid with oil as the continuous image. Water-in-oil emulsion drilling fluid is a stable emulsion system formed by water droplets as the dispersed phase, oil as the continuous phase, and the addition of an appropriate amount of emulsifier, wetting agent, oleophilic colloid and weighting agent.

Zhejiang Camp-Shinning New Material Co., Ltd.  launched two formulations for a domestic oil field company service. The specific formula is:

formula composition
3# 270mL3#White oil+1% Secondary Emulsifier+5%Primary Emulsifier +4%Organoclay+5%Calcium Oxide+3% fine calcium carbonate +30mL30%Brine+5%Filtration control agent+820gBarite(2.2g/cm3)

Pay attention to:Each company's formula is different, if you need to contact us, please E-mail:info@camp-shinning.com whatsapp:86-13735462008

Test embodiment



Φ600

Φ300

AV

(mPa·s)

PV

(mPa·s)

YP

(Pa)

Gel

Pa

Ф6/Ф3

FLHTHP

(ml)

Es

(V)

Room Temperature

163

102

81.5

61

20.5

9.5/10.5

22/20

-

2038

AHR16h

142

85

71

57

14

4/5

11/9

4.2

1522

AHR48

155

91

77.5

64

13.5

4/6

11/9

-

1413

AHR72h后

156

86

78

70

8

2.5/5

6/5

4.2

1021

Note:Aging Temp.:200℃ API:Room Temperature Rheological Temp.:65℃ HTHP

If you are interested in our products, you can contact us E-mail:info@camp-shinning.com whatsapp:86-13735462008
