CP-DRI For Drilling Mud

Specification Bentonite CP-DRI Bentonite CP-DRI is used in vertical drilling fluids to increase viscosity and filtration control. CP-DRI is also ideal in drilling fluids because it expands when exposed to...

  • Brand: CAMP-SHINNING
  • Availability: In Stock
  • SKU: Organic bentonite
  • Barcode:

Tags:

Specification

Bentonite CP-DRI

Bentonite CP-DRI is used in vertical drilling fluids to increase viscosity and filtration control. CP-DRI is also ideal in drilling fluids because it expands when exposed to water. This expansion helps down hole formations to be sealed from invading drilling fluids. The Drilling bentonite extracts the drill cuttings from around the drill bit, which are then floated to the surface. Bentonite also serves to cool and lubricate the drill bit as well as seals the drill hole against seepage and to prevent wall cave-ins. It is mainly use in fresh pure water rotary drilling conditions as water quality will affect bentonite performance.

Bentonite clay Technical Specification

Suspension Properties

 Specification

Appearance

Off-white powder

Viscometer dial reading at 600r/min

Min.30

Plastic viscosity Ratio

Max.3

Filtrate volume

Max.15 ml

Residue of diameter greater than 200mesh

Max mass fraction 5.0%



 Organic bentonite  Advantages

Good suspension

High thixotropy

Little filtrated volume

Excellent capacity of making mud

Easy to adjust the density of the well drilling slurry

Organic bentonite Application

CP-DRI is suitable for all type of freshwater mud rotary drilling.

CP-DRI can also be used as a seal for earthen structures, slurry trenching, tunnel boring and foundation drill.

Mixing and dosage:

Mixing ratios are based on the use of freshwater; water purity will affect bentonite performance. For best results, acidic and hard make-up water should be pretreated with SODA ASH to a pH of 8.5-9.5. Add PREMIUM GEL slowly through jet/hopper mixer.The quantity of bentonite used is variable depending upon the depth of the hole to be drilled. Generally one tonne of bentonite is used to prepare about 100 barrels of mud.

Organic bentonite Packing & Delivery

25kg/bag; or 50kg/bag, packed by 800kg or 1000kg super sacks.

Company Profile

Zhejiang Camp-Shinning New Material Co., Ltd. is a specialized manufacturer of Organoclay Rheological additive and owns million Dollar of fixed assets. As a leading manufacturer and exporter of Organoclay Rheological Additive, we play a vital role in the bentonite market with the annual capacity of 20000 tons; our products take up quarter of the total world's market share, especially in Europe, the America, Middle East, South East Asia, etc. We play a vital role in the bentonite market.

E-mail:info@camp-shinning.com

whatsapp:86-13735462008

FAQ

1.How can we guarantee quality?

(1). Camp-Shinning as the holder of the ISO9001 certificates, which guarantees that all operations are conducted according to the stipulated standards.

(2). All the Organoclay Clay samples we sent to customers for lab test are from mass production which guarantees that consistency of samples and delivery.

(3). Pre-shipment samples are available.

2.Why should you buy Organoclay from us not from other suppliers?

The advantages of Zhejiang Camp-Shinning New Material CO., LTD

(1). With our own mine in north of China, it can ensure the stable performance of our organic bentonite clay raw materials.

(2). 20 years experience in manufacturing and selling of Modified Bentonite.

(3). 7-10days delivery time.

 3.What’s the application of Modified Bentonite?
 Oil Drilling Fluids, Oil Drilling Mud, Paints, Coatings, Inks, Lubricating Grease and wastewater treatment etc.

4.Which countries are you exporting to?
Germany, France, Austria, Spain, USA, Canada, UAE, Pakistan, Russia, Turkey, India,  The Philippines,  Thailand, Vietnam, Indonesia etc.

5.What’s your trade terms for Modified Bentonite?
FOB,CFR,CIF and EXW are available for us.  T/T, L/C and D/P are our common payment term.
